JT550 series inverter is a high-performance vector and torque control inverter. With the speed sensorless vector control technology and torque control technology that is synchronized withthe current international leading technology, it not only has the same excellent control performance
as the international high-end inverter but also further strengthens the reliability of the productand the adaptability of the environment. Its customized and industrialized design can better meetthe needs of various transmission applications as well.

JT550 (1).jpg

Item		Specification
Standard functions	Maximum frequency	320Hz
	Carrier frequency	0.5kHz~16.0kHz The carrier frequency is automatically adjusted based on the temperature
	Input frequency resolution	Digital setting:0.01Hz Analog setting:maximum frequency×0.025%
	Control mode	Voltage/Frequency(V/F) control Sensorless Vector Control (SVC) Feedback Vector Control (FVC)
	Startup torque	G type: 0.5Hz/150% (SVC); 0Hz/180% (FVC) P type: 0.5Hz/100%
	Speed range	1:100(SVC)	1:1000(FVC)
	Speed stability accuracy	±0.5%(SVC)	±0.02%(FVC)
	Torque control accuracy	±0.5% (FVC)
	Overload capacity	G type: 60s for 150% of rated current and 3s for 180% of rated current P type: 60s for 120% of rated current and 3s for 150% of rated current
	Torque boost	Automatic torque boost Manual torque boost 0.1%~30.0%
	V/F curve	Straight-line V/F curve Multi-point V/F curve Square V/F curve
	Ramp mode	Straight-line ramp S-curve ramp Four groups of acceleration/deceleration time with the range of 0.0-6500.0s
	DC braking	DC braking frequency: 0.00Hz to max.frequency Braking time: 0.0-100.0s Braking action current value: 0.0%~100.0%
	JOG control	JOG frequency range: 0.00-50.00 Hz JOG acceleration/deceleration time: 0.0-6500.0s
	Simple PLC, multiply speed running	The system implements up to 16 speeds by using simple PLC function or by using digital input signals.
	Onboard PID	It implements the closed-loop process control system easily.
	Auto voltage regulation (AVR)	The system maintains a constant output voltage automatically when the grid voltage changes through the permissible range.
	Overvoltage& Overcurrent stall control	The current and voltage are limited automatically during the running process so as to avoid frequent tripping due to overvoltage and overcurrent.
	Rapid current limit	It decreases the overcurrent faults to the minimum and ensures normal running of the AC drives
	Torque limit and control	It can limit the torque automatically and prevent frequent overcurrent tripping operation.Torque control is applied in vector control mode.
Individua - lized functions	High performance	high-performance current vector control technology.
	Power dip ride-through	Load feedback energy compensates for any voltage reduction, allowing the drive to continue to operate for a short time during power dips.
	Timing control	Time range: 0.0-6500.0 minutes
	Field bus	Modbus-RTU protocol (485)
Running	Running command source	• Operation panel control • Terminal control • Communication control Allows different methods of switching between command sources:
	Frequency setting channel	Supports up to 13 frequency reference setting channels and allows different methods of switching between frequency reference setting channels: Digital setting Analog voltage reference Analog current reference Pulse reference Communication reference
	Auxiliary frequency setting channel	Supports up to 10 auxiliary frequency sources, and allows fine tuning of the auxiliary frequency and main & auxiliary calculation.
	Input terminals	5 digital input (DI) terminals, X5 supports up to 100 kHz high-speed pulse input; 2 analog input (AI) terminals, AI1 only supports 0-10 V voltage input and AI2 supports 0-10 V voltage input or 4-20 mA current input.
	Output terminals	1 high-speed pulse output terminal (open-collector) that supports 0-100 kHz square wave signal output 1 digital output (DO) terminal 2 relay output terminals(One is factory default, the other is optional) 2 analog output (AO) terminals that supports 0-20 mA current output or 0-10 V voltage output.
Display & operate panel	LED display	Display parameters (three display modes: Basic mode, Quick menu mode, Non-factory value mode).
	Protection function	Phase loss protection; Instantaneous overcurrent protection; overheat protection;Short-circuit protection; overvoltage protection; undervoltage protection; overload protection; overcurrent protection;
	Optional parts	Braking unit, I/O and AI extension card, field bus communication card, differential input PG card, OC input PG card, sin/cos PG card.
Environ ment	Installation location	Indoor, free from direct sunlight, dust, corrosive gas,combustible gas, oil smoke, vapour, drip or salt.
	Altitude	Lower than 1000 m (derated if higher than 1000 m)
	Ambient temperature	-10°C to +40°C (derated if the ambient temperature is between 40°C and 50°C).
	Humidity	Less than 95%RH, without condensing
	Vibration	Less than 5.9 m/s2 (0.6 g)
	Storage temperature	-20ºC~+ 60ºC

Ausenist engaged in the research, development, production, sales and service of the inverters. Our company is positioned to serve the industrial equipment manufacturers, we not only provide customers with practical products and convenient services continuously, but also individually tailored product and comprehensive solution for particular industry.

1/ Trading FAQ
1	Delivery date:	1 week ~2 week,depend on quantity
2	OEM	Accept OEM with your authorization
3	Packaging Details:	Export standard package or special package according to customer requirement
4	Payment Term:	T/T, L/C at sight Western Union or others for negotiation
5	Samples :	Samples will be prepared to sending in about 3-5 working days.
6	Sample Delivery date:	(And DHL 4-7days; UPS 4-7days; Fedex / TNT 4-8days; EMS 9 days to reach destination)
7	Quotation Valid:	Price Valid two months.
8	Warranty :	18 Months
9	Market	Europ, Middle East, South America, Asia, Afria etc
2/ Strictly QC management
1	IQC( Income Quality Control)
2	IPQC( In process Quality Control)
3	FQC( Finish Quality Control)
4	OQC( Outgoing Quality Control)
5	AGING TEST, LOAD TEST AND SO ON
3/ Our advantage
1	More than 20 years-- manufacture of frequency inverter
2	More than 15 years-- experience in OEM items
3	More than 100 countries-- exported
4	More than 50 R&D team-- OEM, ODM accepted
5	More than 100,000 pcs production capacity per month
6	Got NO.6 Inverter brand award in China
7	Got ISO9001,CE ,CCC certificates and Own Patent
8	Experienced and Professional Automation control solution Provider
9	Offer the optional spare parts for frequency inverter & whole solution for automation system.
4/ Products Brief
1	JT550 Series	High Performance Vector control VFD
2	JT300 Series	Economic Vector control VFD
3	JT580 Series	High Protection VFD with built in DC reactor
4	JT550 Series	Through-the-wall Vector control VFD
5	JS500 Series	Construction Lifting Integrated Machine VFD
6	JS500 Series	Material Lifting Integrated Machine VFD
7	Synchronous servo drive
8	Synchronous moter drive
9	Programmable Logic Controller (PLC)
10	3 Phase Permanent Magnet Synchronous High-Efficiency Motor
11	KY550 HDMI
12	TDS servo system

Power range		0.4KW-3.7KW	0.75KW-37KW	Above 37KW
Provision of quality service	Return period	one month	one month	nonsupport
	Exchange period	3 month	3 month	nonsupport
	Warranty period	18 month	18 month	18 month

1. What voltage range can you support?
Single-phase 220v input, single-phase 220v output;
Single-phase 220v input, three-phase 220v output;
Three-phase 220v input, three-phase 220v output;
Single-phase 220v input, three-phase 380v output;

2. How to choose the power of the frequency inverter?
According to your motor power, you can click "Chat Now" on the right and our sales staff will provide you with solutions online.

3. Do you support urgent orders?
Of course. We have an ERP management system. Once there is an inventory warning, we will prepare materials in advance to meet the urgent needs of customers.

5. How to ensure product quality?
Our production strictly follow ISO9001 quality control system. After four times quality inspect and high temperature testing we will print "QA" pass.

6. Do you accept OEM business?
We accept OEM and ODM with your authorization.

7.Can I have a sample order?
Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.

8.What about the lead time?
Sample needed 3-5 days, mass production time needed 1-2 weeks.

9:How about your payment and shipment?
Payment: We accept T/T, Western Union, Paypal etc. terms of payment.
Shipment: For sample order, we use DHL, TNT, FEDEX, EMS etc.express; for batch order, by sea or by air.

10.Do you have any MOQ limit?
1pc for sample checking available.

11.Do you offer guarantee for the products?
Yes, we offer 18 months warranty.
